Technical Specs:

Sensor:

4K Exmor R CMOS

Signal System:

NTSC / PAL

Recording Media:

Dual Slot: CFexpress Type A / SDXC

Resolution:

- Effective: 8.29 Megapixel
- Actual: 12.2 Megapixel

Recording Format:

XAVC-I / XAVC-L (Full-Frame):
- UHD 4K (3840 x 2160) up to 60 fps
- FHD (1920 x 1080) up to 120 fps
- HD (1280 x 720) up to 60 fps


MP4 Proxy:
- AVC/HEVC (1920 x 1080)

Maximum Aperture:

f/1.9

Focal Length:

5.6 to 95.2mm (35mm Equivalent: 30.3 to 515mm)

Zoom:

17x Optical Zoom

Image Stabilization:

Optical in Integrated Lens

Frame Rates:

1 to 120 fps

Autofocus:

AI Autofocus

Built in ND:

Preset ND:
- 2-Stop (1/4)
- 4-Stop (1/16)
- 6-Stop (1/64)
Variable Electronic ND:
- 2-Stop (1/4) to 7-Stop (1/128)

ISO Range:

Gain: -3 to 18 dB (-3 to 42 dB Extended)

Bit Depth:

- 10-Bit 4:2:2 XAVC-I
- 8-Bit 4:2:0 XAVC-L

Battery Type:

14.4V Sony BP-U Series

Weight:

- 5.7 lb / 2.6 kg (Body Only)
- 6.59 lb / 2.99 kg (With Battery)

Audio I/O:

(2) XLR 3-Pin Microphone Input
(1) 1/8" / 3.5 mm TRS Stereo Headphone Output

Video I/O:

(1) BNC (12G-SDI) Output
(1) HDMI 2.0 Output

Power I/O:

(1) USB-C (20VDC at 5 A) Input

Other I/O:

(1) BNC (Timecode) Input/Output
(1) BNC (Genlock, Reference)
(1) RJ45 (Gigabit Ethernet)
(1) 2.5 mm Sub-Mini (Remote)
(1) 1/8" / 3.5 mm Control

IP Streaming:

RTMP / RTMPS / SRT:
- (3840 x 2160) at 25p, 29.97p
- (1920 x 1080) at 25p, 29.97p, 50p, 59.94p
- (1280 x 720) at 25p, 29.97p
