Technical Specs:

Lens Mount:

EF

Sensor:

Super 35mm CMOS Dual Digic DV 5

Signal System:

NTSC / PAL

Recording Media:

- Dual Slot: CFast
- Single Slot: SD (Proxy)

Resolution:

- Actual: 9.84 Megapixel (4206 x 2340)
- Effective: 8.85 Megapixel (4096 x 2160)

Recording Format:

XF-AVC Intra YCC422 10-bit:
- DCI 4K (4096 x 2160) up to 30 fps
- 4K UHD (3840 x 2160) up to 30 fps
- DCI 2K (2048 x 1080) up to 60 fps
- FHD (1920 x 1080) up to 60 fps

XF-AVC Intra RGB444 10/12-bit:
- DCI 2K (2048 x 1080) up to 30 fps
- FHD (1920 x 1080) up to 30 fps

XF-AVC Long GOP YCC422 10-bit:
- DCI 2K (2048 x 1080) up to 60 fps
- FHD (1920 x 1080) up to 60 fps

XF-AVC Long GOP YCC420 8-bit (Proxy):
- DCI 2K (2048 x 1080) up to 60 fps
- FHD (1920 x 1080) up to 60 fps

4K RAW 10-bit Output:
- DCI 4K (4096 x 2160) up to 30 fps
- 4K UHD (3840 x 2160) up to 30 fps

Anamorphic Support:

No

Frame Rates:

1 - 120 fps

Autofocus:

Dual Pixel CMOS AF:
- One-Shot
- AF-Boosted MF
- Continuous
- Face Detect / Tracking
- Focus Guide

Built in ND:

- 2-Stop (1/4)
- 4-Stop (1/16)
- 6-Stop (1/64)
- 8-Stop (1/256)
- 10-Stop (1/1024)

ISO Range:

- Base: 400
- Range: 100 to 102,400

Bit Depth:

- 12-bit RGB444
- 10-bit YCC422 / RGB444

Battery Life (approximate):

Approx. 200 min.

Battery Type:

Canon BP-A Series

Weight:

7.6 lb / 3.44 kg

Audio I/O:

(2) 3-Pin XLR Input (+48 V Phantom Power)
(1) 1/8" / 3.5 mm TRS Stereo Microphone Input
(1) 1/8" / 3.5 mm TRS Stereo Headphone Output

Video I/O:

(2) BNC (3G-SDI) Output
(1) HDMI Output

Power I/O:

(1) 4-Pin LEMO Input

Other I/O:

(1) BNC (Timecode) Input
(1) BNC (Genlock Input / Sync Output)
(1) 2.5 mm TRS (LANC) REMOTE Input
