Technical Specs:

Lens Mount:

RF

Sensor:

Full-Frame BSI Stacked CMOS

Signal System:

NTSC / PAL

Recording Media:

Dual Slot: SD

Resolution:

- Actual: 26.67 Megapixel (6202 x 4300)
- Effective: 24.07 Megapixel (6008 x 4000)

Recording Format:

Cinema RAW Light 12-bit:
- FF 6K (6000 x 3164) up to 30 fps
- S35 4.3K (4368 x 2304) up to 60 fps

XF-AVC
S Intra 4:2:2 10-bit / Long GOP 4:2:0 8-bit::
- DCI 4K (4096 x 2160) up to 120 fps
- 4K UHD (3840 x 2160) up to 120 fps
- DCI 2K (2048 x 1080) up to 180 fps
- FHD (1920 x 1080) up to 180 fps

XF-HEVC
S Long GOP 4:2:2 / 4:2:0 10-bit:
- DCI 4K (4096 x 2160) up to 120 fps
- 4K UHD (3840 x 2160) up to 120 fps
- DCI 2K (2048 x 1080) up to 180 fps
- FHD (1920 x 1080) up to 180 fps

XF-HEVC S Long GOP 4:2:0 10-bit:
- DCI 2K (2048 x 1080) up to 60 fps
- FHD (1920 x 1080) up to 60 fps

XF-HEVC S Long GOP 4:2:0 8-bit:
- HD (1280 x 720) up to 60 fps

Anamorphic Support:

Monitoring Only:
- 2.0x
- 1.8x
- 1.3x

Frame Rates:

1 - 180 fps

Autofocus:

Dual Pixel CMOS AF II:
- Continuous-Servo
- One-Shot
- Subject Detection / Tracking
- Focus Guide

Built in ND:

- 2-Stop (1/4)
- 4-Stop (1/16)
- 6-Stop (1/64)
- 8-Stop (1/256)
- 10-Stop (1/1024)

ISO Range:

Triple-Base ISO:
- 800
- 3200
- 12,800
Native:
- 100 to 102,400

Bit Depth:

- 12-bit Cinema RAW Light
- 10-bit XF-AVC YCC422
- 8-bit XF-AVC YCC420

Battery Type:

14.4 V Canon BP-AN Series

Weight:

- 2.87 lb / 1.30 kg (Body Only)
- 3.406 lb / 1.545 kg (With Battery, Handle)

Audio I/O:

(2) Mini XLR Input
(1) 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body
(1) 1/8" / 3.5 mm TRS Stereo Headphone Output

Video I/O:

(1) BNC (12G-SDI) Output
(1) HDMI Output

Power I/O:

(1) Barrel (23.7 to 25VDC) Input

Other I/O:

(1) RJ45 (XC) Control
(1) USB-C Monitor
(1) BNC (Timecode) Input / Output
(1) 2.5 mm Sub-Mini (LANC) Control
