Technical Specs:

Mount Type:

RF

Sensor:

Full-Frame CMOS Sensor

Shutter Type:

Electronic Rolling Shutter

Signal System:

NTSC / PAL

Recording Media:

- Slot 1: CFexpress Type B
- Slot 2: SD

Record Time:

Unlimited

Recording Format:

Cinema RAW Light 12-bit:
- FF 7K 3:2 Open Gate (6960 x 4640) up to 30 fps
- FF 6.9K (6960 x 3672) up to 60 fps
- S35 5K (5036 x 2656) up to 60 fps

XF-AVC 10-bit:
- FF DCI 4K (4096 x 2160) up to 60 fps
- FF 4K UHD (3840 x 2160) up to 120 fps
- FF DCI 2K (2048 x 1080) up to 180 fps
- FF FHD (1920 x 1080) up to 180 fps

XF-HEVC S 10-bit:
- FF 7K 3:2 Open Gate (6912 x 4608) up to 30 fps
- FF DCI 4K (4096 x 2160) up to 120 fps
- FF 4K UHD (3840 x 2160) up to 120 fps
- FF DCI 2K (2048 x 1080) up to 180 fps
- FF FHD (1920 x 1080) up to 180 fps

Resolution:

Approx. 34.2 Megapixel (7144 x 4790)

Frame Rates:

1 - 180 fps

Bit Depth:

- 12-bit Cinema RAW Light
- 10-bit XF-HEVC S YCC422
- 10-bit XF-AVC YCC422
- 8-bit XF-AVC YCC420

ISO Range:

Canon Log 2 / 3:
- Dual Base ISO: 800 / 6400
- Native: 100 to 25,600

PQ / HLG / Canon 709 / BT.709 Wide DR:
- Dual Base ISO: 400 / 3200
- Native: 100 to 25,600

BT.709 Standard:
- Dual Base ISO: 160 / 1250

Autofocus:

Dual-Pixel CMOS AF II:
- Continuous-Servo
- One-Shot
- Subject Detection / Tracking
- Focus Guide

Anamorphic Support:

Monitoring Only:
- 2.0x
- 1.8x
- 1.5x
- 1.3x

Display:

Articulating 3" Touchscreen LCD

Viewfinder:

No

Image Stabilization:

No

Built in ND:

No

Built-In Mic:

Stereo

Battery Type:

7.2 V Canon LP-E6P

Battery Life (approximate):

Approx. 90 min.

Wireless:

Wi-Fi / 2.4 GHz Radio/RF / 5.8 GHz Radio/RF

Video I/O:

(1) HDMI Output

Audio I/O:

Body:
(1) 1/8" / 3.5 mm TRS Stereo Input
(1) 1/8" / 3.5 mm TRS Stereo Output

Top Handle:
(2) 3-Pin XLR / 1/4" TRS Input

Power I/O:

(1) USB-C Input (45 W PD) / Ethernet

Other I/O:

(1) 2.5 mm Sub-Mini (Remote) Control Input
(1) DIN 1.0/2.3 (Timecode) Input / Output
(1) Intelligent Hot Shoe

Weight:

- 23.5 oz / 665 g (Body Only)
- 2.4 lb / 1110 g (With Battery, Handle, Recording Media)

Operating Conditions:

23 to 113°F / -5 to 45°C at 60 to 85% Humidity
