Technical Specs:

Input

(1) BNC (3G-SDI)
(1) HDMI (Type A)

Input Formats

- SDI: DCI 2K (2048 x 1080) up to 60 fps
- HDMI: FHD (1920 x 1080) up to 60 fps

Output

(1) Thunderbolt 3

Audio I/O

- SDI: 16-Channels Embedded in SD/HD
- HDMI: 8-Channels Embedded in SD/HD

Power Supply

Powered by Thunderbolt 3 Cable

Settings Control

Requires OS:
MAC 10.7 or Later
MAC 10.8 or Later

Color Precision

10-bit

Color Space

REC 601, REC 709

Color Space

- REC 601
- REC 709
- REC 2020

Color Precision

SDI:
- 12-Bit 1080p RGB 4:4:4 up to 30 fps
- 10-Bit YUV 4:2:2 in All Standards

HDMI:
8-Bit RGB 4:4:4
8-Bit YUV 4:4:4
12-Bit YUV 4:2:2 in All Standards

Audio Sampling

48 kHz & 24-bit

Dimensions

3.62 x 1.77 x 0.98"

Weight

5.57 oz
